Hudi Merge-on-Read: the write you skipped, and the read that pays for it

• Architecture: what the table looks like on disk
• Why append instead of rewriting the file?
• What is actually inside a log file?
• What do the three query types return?
• Who runs compaction?
• When should compaction trigger?
• How do I tell the table is healthy?
• How does the timeline record all this?
• What happens when two jobs write at once?
• When is Copy-on-Write the better choice?
• Frequently asked questions
• Conclusion
• References

TL;DR

• Merge-on-Read appends each write to a log file beside the base Parquet file instead of rewriting it. The base file plus its logs, at a moment in time, is a file slice.
• A log file is not a Parquet file. It is a Hudi container of blocks separated by the marker #HUDI#, and one of the seven block types exists purely to mark an earlier block as rolled back.
• The same file slice answers three different questions. snapshot merges base plus logs, read_optimized reads only the base file, and hudi_table_changes returns what changed between two instants.
• Compaction folds the logs back into a new base file, and for Spark writers it is opt-in: hoodie.compact.inline defaults to false. Deciding who runs it is the one setup step the table asks of you.
• hudi_filesystem_view gives you the health check in one query: it reports log file count and unscheduled log size per file group.

The question I hear most often about Merge-on-Read goes something like this. The writes are great. A change stream lands every minute, the job finishes in seconds, nobody is rewriting hundred-megabyte Parquet files any more. But the dashboards on the same table have been getting a little slower each week, and nothing in the pipeline changed.

Nothing is broken when that happens. Merge-on-Read is doing exactly what it promises: it takes the cost of an update off the writer and puts it somewhere else. The useful thing to know is precisely where that somewhere else is, and that Hudi leaves one decision about it to you rather than making it silently.

So let us open the format up. By the end you should be able to read a Merge-on-Read directory listing and say which writes are still waiting to be compacted, pick a compaction trigger from how your writes actually arrive, and predict what each query type will return before you run it.

Written against the latest Hudi release, 1.2.0 as of now, whose Spark bundles cover Spark 3.3 through 4.1. Every config key, default, enum value and on-disk path below was read from that release’s tag rather than recalled, and where a claim is specific to a version the version is named. Useful background: the Hudi table types page.

Architecture: what the table looks like on disk

Start with the artefact, because it answers most of the questions by itself. Here is one partition of a trips table:

s3a://lakehouse-prod/warehouse/trips/city_id=sf/
├── 8f3a1c92-4f1e-4c77-9a2b-4b1d2e3f4a5b-0_0-24-1893_20260915090000123.parquet
├── .8f3a1c92-4f1e-4c77-9a2b-4b1d2e3f4a5b-0_20260915090000123.log.1_0-31-2104
└── .8f3a1c92-4f1e-4c77-9a2b-4b1d2e3f4a5b-0_20260915090000123.log.2_0-38-2415

One Parquet file and two log files, and all three share the leading UUID. That UUID is the file ID, and it names a file group: Hudi’s unit of record locality. Once a record key lands in a file group, every later update to that key goes to the same group. That is the whole reason an update can be a local operation rather than a table-wide one.

Read the log file name left to right and it explains itself. HoodieLogFile sets LOG_FILE_PREFIX to ., which is why log files are hidden from a plain listing, and why a casual ls on a Merge-on-Read partition can look exactly like Copy-on-Write. Then the file ID, then the base instant time the log was written against, then .log from DELTA_EXTENSION, a version number, and a write token.

That base instant in the log name is the piece doing the real work. It ties each log to its base file, which is how a reader assembles the pair without relying on any directory convention. Base file plus its logs at a moment in time is a file slice, and a new base file starts a new slice:

flowchart LR
  S1["slice 1<br/>base @ t1"] --> L1["log .1<br/>@ t2"]
  L1 --> L2["log .2<br/>@ t3"]
  L2 --> CP["compaction<br/>@ t4"]
  CP --> S2["slice 2<br/>base @ t4"]
  S2 --> L3["log .1<br/>@ t5"]

Why append instead of rewriting the file?

Because of what the alternative costs. Copy-on-Write, Hudi’s other table type, applies a correction to one trip by reading the Parquet file that holds it, merging the change, and writing a whole new file. Change one row in a 120 MB file and you have written 120 MB.

That is a perfectly good trade when writes are occasional and reads are constant. It stops being a good trade when the change stream delivers every minute, because then you are rewriting a large share of the table every minute, and each rewrite is competing with the batch behind it.

Merge-on-Read takes the opposite side. The change is appended beside the base file and the write returns. Nothing large is rewritten. The cost moves to the reader, which now reconciles base with logs, and to a compaction job that eventually folds the logs back into a fresh base file.

One sentence worth carrying: Merge-on-Read buys low write latency at the cost of read-side merge work and a compaction job somebody operates.

What is actually inside a log file?

This is where Merge-on-Read stops resembling anything else on the lake, and opening it up explains several behaviours that otherwise look arbitrary.

A Hudi log file is a container of blocks. HoodieLogFormat separates them with a six-byte magic marker:

byte[] MAGIC = new byte[] {'#', 'H', 'U', 'D', 'I', '#'};

Each block carries a type, a header map, a payload and a footer. HoodieLogBlockType has seven values:

Two of those repay a second look.

COMMAND_BLOCK is how rollback works without deleting anything. A failed write leaves its blocks sitting in the log. Instead of rewriting the log to remove them, Hudi appends a command block naming the instant to invalidate, and readers skip the blocks it points at. Append-only storage stays append-only, and rollback stays a metadata operation.

CORRUPT_BLOCK is a deliberate choice, not an accident. A truncated write on object storage leaves a partial block behind. Rather than failing the read, the reader classifies it as corrupt and scans forward to the next magic marker. One bad append does not cost you the file.

The block headers carry what a reader needs to reconcile. HeaderMetadataType includes INSTANT_TIME, TARGET_INSTANT_TIME, SCHEMA, COMMAND_BLOCK_TYPE, COMPACTED_BLOCK_TIMES, RECORD_POSITIONS, BLOCK_IDENTIFIER, IS_PARTIAL and BASE_FILE_INSTANT_TIME_OF_RECORD_POSITIONS.

SCHEMA in that list is why schema evolution survives the read path: a block written under an older schema carries that schema along with it, so a reader on the current schema can still interpret it. RECORD_POSITIONS enables positional merging, where a reader applies changes by position instead of joining on the record key.

Block size is bounded by hoodie.logfile.data.block.max.size at 256 MiB, and the log file itself rolls over at hoodie.logfile.max.size, 1 GiB.

What do the three query types return?

A file slice does not have one answer. It has three, and Hudi asks you to say which one you want:

In Spark SQL the first two come from the hudi_query table-valued function, whose second argument accepts exactly snapshot or read_optimized:

-- Everything committed, including whatever is still sitting in log files.
SELECT count(*) FROM hudi_query('trips', 'snapshot');

-- Base files only: misses everything written since the last compaction, and in
-- exchange reads like ordinary Parquet with no merge.
SELECT count(*) FROM hudi_query('trips', 'read_optimized');

Incremental reads are a separate function, because they take an instant range rather than a mode:

-- What changed after this instant. 'earliest' is also accepted as a start.
SELECT trip_id, city_id, fare_amount, status, updated_at
FROM hudi_table_changes('trips', 'latest_state', '20260915090000123');

The gap between the first two counts is exactly the set of writes not yet compacted, which turns the pair into a free diagnostic. Equal counts mean compaction has caught up. A gap that widens week over week is the slow dashboard from the top of this post, showing up as a number before anyone complains.

On a Copy-on-Write table the two are always identical, because there are no logs to merge. Worth remembering when somebody reports that read_optimized “does nothing”: on Copy-on-Write, correctly, it does nothing.

Who runs compaction?

Compaction reads a file slice, merges the base file with its logs, and writes a new base file that begins the next slice. It is scheduled on the timeline as a compaction action and moves through .requested, .inflight and completed like any other Hudi action.

Here are the defaults that decide when that happens:

hoodie.compact.inline                     false
hoodie.compact.inline.max.delta.commits   5
hoodie.compact.inline.max.delta.seconds   3600
hoodie.compact.inline.trigger.strategy    NUM_COMMITS
hoodie.compaction.strategy                LogFileSizeBasedCompactionStrategy
hoodie.compaction.target.io               512000

The first line is the one to notice. hoodie.compact.inline is false, so a Spark writer on the defaults never compacts as part of the write. Something else has to: an async compaction service, a scheduled offline job, or simply turning inline compaction on. This is the decision Hudi hands you rather than guessing, and it is a sensible thing to leave open, because on a busy table you usually do not want compaction sharing a critical path with ingestion.

Inline is the simplest answer, and it goes in the table definition:

CREATE TABLE IF NOT EXISTS trips (
  trip_id      STRING,
  city_id      STRING,
  driver_id    STRING,
  fare_amount  DECIMAL(10,2),
  status       STRING,
  updated_at   TIMESTAMP
) USING hudi
PARTITIONED BY (city_id)
LOCATION 's3a://lakehouse-prod/warehouse/trips'
TBLPROPERTIES (
  type = 'mor',
  primaryKey = 'trip_id',
  orderingFields = 'updated_at',
  -- Compact inside the writer every fifth delta commit. Easy to reason about,
  -- and it makes every fifth write noticeably slower.
  hoodie.compact.inline = 'true',
  hoodie.compact.inline.max.delta.commits = '5',
  hoodie.compact.inline.trigger.strategy = 'NUM_COMMITS'
);

Off the write path, the procedures do the same job on your schedule:

-- What is pending, and how much of it is there?
CALL show_compaction(table => 'trips', limit => 10);

-- Schedule a compaction instant, then execute it. `op` selects the phase.
CALL run_compaction(op => 'schedule', table => 'trips');
CALL run_compaction(op => 'run', table => 'trips');

Inline compaction buys operational simplicity at the cost of latency on the triggering commit. Async or offline compaction buys steady write latency at the cost of a second thing to schedule and watch.

When should compaction trigger?

CompactionTriggerStrategy offers five options, and the right one usually falls straight out of how your writes arrive:

The difference between the first two only shows up when compaction is falling behind. Under NUM_COMMITS, requests keep being scheduled because none have completed, and the backlog grows. Counting from the last request instead keeps the queue bounded, which is why it is the safer choice on a table that has ever lagged.

A second knob decides what gets compacted in one run. hoodie.compaction.strategy defaults to LogFileSizeBasedCompactionStrategy, taking the file groups with the largest total log size first, bounded by hoodie.compaction.target.io. That bound is in MB and defaults to 512000, or 500 GB per run, so on most tables the default means “everything eligible”. When that is too blunt, LogFileNumBasedCompactionStrategy sorts by log file count, DayBasedCompactionStrategy and PartitionRegexBasedCompactionStrategy scope by partition, and CompositeCompactionStrategy chains several together.

The arithmetic you actually need is simple. Divide your commit frequency by your trigger and you have the worst staleness a read_optimized reader will ever see. Commits every minute with max.delta.commits = 5 means that reader is at most five minutes behind, and a snapshot query merges at most five log files.

How do I tell the table is healthy?

One query answers it. hudi_filesystem_view reports the physical state of every file group, and its schema (from FileSystemRelation) is exactly the set of columns this question needs:

SELECT File_ID,
       Partition_Path,
       Base_Instant_Time,
       Log_File_Count,
       Log_File_Scheduled,
       Log_File_Unscheduled
FROM hudi_filesystem_view('trips')
ORDER BY Log_File_Unscheduled DESC
LIMIT 20;

Log_File_Unscheduled is the column to watch: log bytes that no compaction has even been planned for yet. A small, steady number across file groups means the trigger matches the write rate. A number that climbs week over week means compaction is not keeping up, and it climbs long before anyone notices a slow query.

A healthy Merge-on-Read table has a handful of recognisable properties:

Put one of these on a schedule rather than running it when somebody complains, because this signal is a quiet one. Nothing raises an error when compaction stops; snapshot queries simply merge a little more each hour.

How does the timeline record all this?

Every change to a Hudi table is an instant on the timeline, and the timeline is just files. After four writes to the table above:

ls -1 /tmp/hudi_mor/.hoodie/timeline

20260921111139627_20260921111143473.deltacommit
20260921111139627.deltacommit.inflight
20260921111139627.deltacommit.requested
20260921111143544_20260921111144466.deltacommit
20260921111143544.deltacommit.inflight
20260921111143544.deltacommit.requested
...
history

Each write leaves three files, one per state, and that is the whole mechanism:

A reader builds its view from completed instants only, which is where Hudi’s isolation comes from. A writer that dies mid-write leaves a .inflight with no completed file, so readers never see it, and a later write rolls it back. Nothing needs to be locked for a reader to be correct.

Two details are specific to Hudi 1.x and will surprise you if you learned the 0.x layout. The timeline moved from .hoodie/ into .hoodie/timeline/, and completed instants now carry two timestamps: the instant time it began and the time it completed, joined by an underscore. That second timestamp is what makes non-blocking concurrency possible, because ordering by completion is well defined even when two writers overlap.

The history directory beside them is the archived timeline. Instants are moved there once they age out, which keeps the active timeline small enough to list cheaply. An archived instant is still a record of what happened and is no longer consulted on every read.

The action name tells you what happened, and Merge-on-Read uses a different one from Copy-on-Write:

If you ever want to know what a Hudi table has been doing, list that directory before you reach for anything else.

What happens when two jobs write at once?

Nothing good, unless you tell Hudi to expect it. The default is single writer:

hoodie.write.concurrency.mode  default=SINGLE_WRITER

In that mode Hudi assumes one writer per table and does not coordinate. Two concurrent jobs can both succeed and one can lose its changes, which is the failure people discover after it has already happened.

Turning on optimistic concurrency control makes conflicting writes fail loudly instead:

opts = {
  "hoodie.write.concurrency.mode": "optimistic_concurrency_control",
  "hoodie.write.lock.provider": "org.apache.hudi.client.transaction.lock.InProcessLockProvider",
}

The name is accurate. Writers do not hold a lock for the duration of their work; they write, then take a short lock at commit time to check whether anything they touched was changed underneath them. If it was, one of them aborts and you retry it. That is cheap when writers rarely collide and expensive when they always do, which is the trade-off to think about before enabling it.

The lock provider is the part that needs real infrastructure. InProcessLockProvider is for a single JVM and is fine for a test; a real deployment uses ZooKeeper, the Hive metastore, or DynamoDB, because the lock has to be visible to every writer across every machine.

Merge-on-Read changes the calculus here. Two writers appending log files to the same file group are not necessarily in conflict, because appends do not overwrite each other, which is why MOR tables tolerate concurrent ingest better than Copy-on-Write ones. Compaction is the operation that must be coordinated, and running it asynchronously from a single dedicated job is the usual answer.

When is Copy-on-Write the better choice?

Merge-on-Read is not Hudi’s default: type defaults to cow. That is the right default for plenty of tables, and picking it deliberately is a good outcome too.

If writes arrive a few times a day, there is not much to win. Copy-on-Write rewrites base files on each write, but a handful of rewrites a day is cheap, and every read is then a plain Parquet scan with no merge and no compaction job in the picture.

If reads vastly outnumber writes and have to be fast, Copy-on-Write puts the cost where you have the most slack. Merge-on-Read moves work from the rare operation to the frequent one, which is the wrong direction for a table read constantly and written nightly.

And if no one is going to own the compaction job yet, Copy-on-Write is the kinder choice. You can always convert later once someone does.

Merge-on-Read earns its keep when writes are frequent, each batch is small relative to the table, and either you can absorb the merge on read or your heaviest consumers are happy on read_optimized.

Frequently asked questions

Why does my Merge-on-Read partition look like Copy-on-Write? Log files begin with a dot, so most listings hide them. Use hudi_filesystem_view instead of a directory listing and the log file counts appear.

Do I have to compact to read the latest data? No. A snapshot query always returns the latest committed state, compacted or not. Compaction changes what that read costs, not what it returns.

Can I query a Merge-on-Read table from Trino or Athena? Yes, and which query type you get depends on the table name the engine was given. Hive sync registers a Merge-on-Read table under two names, and HiveSyncTool spells the suffixes out: _rt serves snapshot reads and _ro serves read-optimized reads. If an external engine looks a commit behind, check which of the two the catalog handed it.

What happens if a compaction job fails halfway? Nothing a reader can see. Compaction is an instant on the timeline like any other, so an incomplete run sits at .inflight and the base file it was going to replace is untouched. Hudi rolls failed instants back, and HoodieCompactor takes --retry-last-failed-job to roll back and re-execute the last failed plan rather than planning a new one.

Should I change hoodie.logfile.max.size? Rarely. At 1 GiB the default rolls a log file over long before it becomes unwieldy, and lowering it mostly produces more small files for compaction to deal with.

Does the metadata table matter here? More than on Copy-on-Write. Planning a Merge-on-Read query means resolving file slices across base and log files, and the metadata table is what keeps that listing work off the critical path.

Conclusion

Back to the dashboards getting slower. In almost every case the table was working precisely as designed, and the one decision Merge-on-Read asks for, who runs compaction, had never quite been made. Once it was, the curve went flat and stayed flat.

The design underneath is worth knowing because it turns a set of odd-looking behaviours into a single idea. Log files hide behind a leading dot. Rollback deletes nothing, it appends a command block. A truncated write does not break a read, because corrupt blocks are a first-class block type. Schema evolution survives the log, because every block carries the schema it was written under. All of that follows from one choice: an append-only container instead of mutation in place.

If you are setting up a Merge-on-Read table this week, two decisions carry most of the outcome, and both are above. Pick a compaction trigger that matches how your writes actually arrive, and decide which consumers need snapshot and which are perfectly happy on read_optimized. Get those right and the table stays flat and predictable for a long time.

References

• Hudi table types for Copy-on-Write versus Merge-on-Read and the query types each supports
• Hudi compaction documentation for inline, async and offline scheduling
• HoodieLogBlock.java, the block types and header metadata described above
• HoodieCompactionConfig.java for every compaction key and its default
• Open table formats in practice for how this compares with Iceberg and Delta Lake
