The Hudi index: how one lookup decides the cost of every upsert

• What does the index actually decide?
• What are the options?
• Architecture: where does the index live?
• Which record index, global or partition-scoped?
• What about bucket, bloom and simple?
• What does the metadata table do for the index?
• Which one should I pick?
• How do I confirm it is working?
• Frequently asked questions
• Conclusion
• References

TL;DR

• The index answers one question on every write: for this record key, which file group already holds it? Answering it well is what keeps upsert cost proportional to your batch instead of your table.
• hoodie.index.type has no default of its own. Spark and Java fall back to SIMPLE, Flink to INMEMORY, decided in code rather than in the config file.
• The 1.x line gives the record index two clearer names: GLOBAL_RECORD_LEVEL_INDEX for keys unique table-wide, and RECORD_LEVEL_INDEX for keys unique within a partition. RECORD_INDEX is the older name for the global one.
• Each has its own enabling config and its own sizing defaults, tuned to what it stores: 10 to 10000 file groups for the global index, 1 to 10 for the partitioned one.
• The old key hoodie.metadata.record.index.enable is a registered alias, so upgrades are uneventful. It resolves to the global index, so use the new names when you want the partitioned one.

There is a particular shape of complaint about upsert jobs that always turns out to be the same thing. The job was fine in month one. By month six it takes noticeably longer, and the batch has not grown; the table has. Somebody adds executors, which helps for a while.

The batch is not what the job is spending its time on. Before Hudi can apply a single update it has to find out, for every incoming key, whether that key already exists and which file group holds it. That step is called tagging, and on the default configuration its cost tracks the size of the table rather than the size of the batch. Grow the table, and you grow the work that happens before any real work starts.

Choosing an index is choosing how that lookup happens. It is one of the more tractable decisions Hudi asks of you, because the two things that decide the answer, how big your batches are relative to your table and how your keys are distributed, are both things you can just look at.

Written against the latest Hudi release, 1.2.0 as of now, whose Spark bundles are published for Spark 3.3 through 4.1. Every config key, default and enum value below was read from the release-1.2.0 tag rather than recalled, which matters here because several of these names changed across 1.1.0 and 1.2.0; where a claim is specific to a version, the version is named. Two terms used throughout: a file group is the unit of record locality in a Hudi table, identified by a file ID, and a file slice is one version of a file group, a base file plus any log files written against it.

What does the index actually decide?

Everything downstream of tagging depends on its answer: whether a record becomes an insert into a new file slice or an update merged into an existing one, how much data gets rewritten, and how much shuffle the write incurs.

flowchart LR
  B["incoming batch<br/>of records"] --> T["tagging"]
  IX["the index"] --> T
  T --> U["update<br/>merge into the<br/>existing file group"]
  T --> I["insert<br/>into a new<br/>file slice"]

The obvious way to do it is a join: read the record keys out of every file in the table, join the incoming batch against them, done. That is essentially what SIMPLE does, and it is correct, predictable and easy to reason about. Its cost just happens to track the table.

Every other index type is a different strategy for skipping that scan. Hudi ships enough of them that one will fit your key distribution.

What are the options?

HoodieIndex.IndexType is the authoritative list, and it has ten values:

“Global” is the word to read carefully. A global index enforces that a record key is unique across the whole table, which also lets it move a record between partitions when its partition value changes. A non-global index only guarantees uniqueness inside a partition, so the same key can legitimately live in two partitions and an update has to be told which one it means.

That is a data-model decision, not a performance one, and your schema already answers it. If a customer row is partitioned by country and the customer moves country, a global index updates the existing record and removes it from the old partition, leaving one live row. A non-global index treats the two partitions independently, which is the correct behaviour when a key legitimately repeats across partitions.

One thing worth doing regardless of which you pick: write the choice down. hoodie.index.type is declared with noDefaultValue(), and the real default is picked in HoodieIndexConfig.Builder#getDefaultIndexType based on the engine:

switch (engineType) {
  case SPARK:
  case JAVA:
    return HoodieIndex.IndexType.SIMPLE.name();
  case FLINK:
    return HoodieIndex.IndexType.INMEMORY.name();
  ...
}

So a Spark writer that never sets the key is running SIMPLE. That is a reasonable place to start, and setting it explicitly costs one line and makes the decision visible to whoever reads the config next.

Architecture: where does the index live?

The metadata-backed indexes are the interesting ones, so it is worth being concrete about where they sit.

Hudi keeps an internal Hudi table inside your table, at <base_path>/.hoodie/metadata, from HoodieTableMetaClient.METADATA_TABLE_FOLDER_PATH. It is itself a Merge-on-Read table, which is how it absorbs high-frequency updates without rewriting everything, and it is on by default: hoodie.metadata.enable has defaulted to true since 0.7.0.

Each kind of metadata lives in its own partition of that table:

s3a://lakehouse-prod/warehouse/trips/
├── .hoodie/
│   ├── metadata/                       <- the internal metadata table
│   │   ├── files/                      <- partition to file listing
│   │   ├── column_stats/               <- per-column min/max per file
│   │   ├── bloom_filters/              <- bloom filters, for BLOOM lookups
│   │   ├── record_index/               <- record key to file group
│   │   ├── partition_stats/
│   │   ├── expr_index_<name>/
│   │   └── secondary_index_<name>/
│   └── <instant files: .commit, .deltacommit, .clean, ...>
├── city_id=sf/
│   ├── 8f3a1c92-....parquet            <- base file of one file slice
│   └── .8f3a1c92-....log.1_0-...       <- log file, Merge-on-Read
└── city_id=nyc/

The record_index partition is the key-to-location map, sharded across file groups whose IDs are prefixed record-index-. Tagging with a record index is a point lookup into those file groups rather than a scan of the data table, and its cost scales with the incoming batch. That is the whole point.

It is worth separating the write path from the read path here, because the two get conflated constantly. Tagging uses record_index. Query-side data skipping uses column_stats and partition_stats, which let an engine prune file groups by column ranges before reading data. Turning on a record index therefore does nothing for query performance, and turning on column stats does nothing for upsert cost. Same table, different partitions, separate configs.

The trade: a record index buys batch-proportional tagging at the cost of a second table to keep consistent. Every write to the data table also writes to the metadata table, the metadata table needs its own compaction (hoodie.metadata.compact.max.delta.commits), and the index has to be bootstrapped over existing data before it is usable.

Which record index, global or partition-scoped?

In 0.14.0 Hudi added one record index, enabled with hoodie.metadata.record.index.enable, exposed as RECORD_INDEX. It was global: keys unique across the table.

1.1.0 added a partition-scoped variant, and in 1.2.0 the original enum value carries @Deprecated, with the replacement named in its own description. The configs were renamed to match, keeping the old names as registered alternatives:

Two things to take from that table.

The old key is an alias for the global one. withAlternatives means hoodie.metadata.record.index.enable=true still resolves, and it resolves to GLOBAL_RECORD_LEVEL_INDEX, so nothing breaks when you upgrade. If your keys are only unique per partition, moving to RECORD_LEVEL_INDEX is a two-line change that buys a smaller index and less metadata to maintain.

The file-group defaults are matched to what each one stores. The global index shards a map of every key in the table, so it floors at 10 file groups and ceilings at 10000. The partitioned index maps keys within a partition, so its defaults are 1 and 10. Let each keep its own defaults and the sizing looks after itself. The one thing worth avoiding is carrying the global counts across to the partitioned index, which creates far more file groups than the data needs.

Sizing has two more inputs, both unchanged across these releases: file groups cap at hoodie.metadata.record.index.max.filegroup.size (1 GiB, because a large file group takes longer to compact), and the estimate of how many you need multiplies the current record count by hoodie.metadata.record.index.growth.factor (2.0) to leave headroom.

Here is a partitioned table whose keys are unique within a city, in Spark SQL:

CREATE TABLE IF NOT EXISTS trips (
  trip_id      STRING,
  city_id      STRING,
  rider_id     STRING,
  fare_amount  DECIMAL(10,2),
  started_at   TIMESTAMP,
  updated_at   TIMESTAMP
) USING hudi
PARTITIONED BY (city_id)
LOCATION 's3a://lakehouse-prod/warehouse/trips'
TBLPROPERTIES (
  type = 'mor',
  primaryKey = 'trip_id',
  orderingFields = 'updated_at',
  -- trip_id is unique per city, not across cities, so the partition-scoped
  -- index is both the correct one and the cheaper one.
  hoodie.index.type = 'RECORD_LEVEL_INDEX',
  hoodie.metadata.enable = 'true',
  hoodie.metadata.record.level.index.enable = 'true'
);

If the key is a true primary key across the whole table, the same definition takes the global pair instead:

  hoodie.index.type = 'GLOBAL_RECORD_LEVEL_INDEX',
  hoodie.metadata.enable = 'true',
  hoodie.metadata.global.record.level.index.enable = 'true'

Decide this when you create the table rather than later. Prefer those names over hoodie.metadata.record.index.enable even though the old one still resolves, because the explicit name says which of the two indexes you meant.

A related rename to follow rather than fix: orderingFields above is the SQL spelling of hoodie.table.ordering.fields, which keeps hoodie.table.precombine.field as an alias. On the DataFrame side hoodie.datasource.write.precombine.field is marked @Deprecated in 1.2.0 but still works, because DataSourceOptions.ORDERING_FIELDS resolves to it.

What about bucket, bloom and simple?

The record index is not always the answer.

BUCKET does no lookup at all. It hashes the key to a fixed number of buckets and derives the file group from the hash, so tagging costs nothing and there is no index to maintain or bootstrap. The price is that the bucket count becomes part of your physical layout. hoodie.bucket.index.num.buckets sets it and hoodie.bucket.index.hash.field defaults to the record key field. Get the count wrong and every file group is either tiny or enormous, with no incremental way out, which is exactly why hoodie.index.bucket.engine offers a consistent-hashing engine alongside the simple one: buckets can then split and merge (hoodie.bucket.index.split.threshold, hoodie.bucket.index.merge.threshold). Bucket index buys free tagging at the cost of committing to a partitioning of the key space up front.

BLOOM prunes candidate files instead of scanning them. Hudi writes a bloom filter per file, tests incoming keys against the filters, and only opens the files that might hold a match. hoodie.bloom.index.prune.by.ranges narrows it further using min and max key ranges, and hoodie.bloom.index.use.metadata reads the filters from the metadata table’s bloom_filters partition rather than from file footers. It shines when keys are roughly ordered, because narrow ranges let it skip most files. With random keys such as UUIDs the ranges overlap and there is less to prune, which is where a record index takes over.

SIMPLE is the dependable one. It joins, and it has no index to bootstrap or keep in step with the data. For small tables, or batch jobs that rewrite most of the table anyway, that simplicity is worth more than a faster lookup.

What does the metadata table do for the index?

Every index above has to answer “which files might hold this key”, and before it can do that something has to know which files exist. On object storage, listing them is the expensive part: a LIST on a prefix with thousands of partitions is slow, rate-limited, and repeated on every write.

Hudi’s answer is to keep that information in a table of its own, and it is on by default:

hoodie.metadata.enable  default=true

It lives inside the table it describes, and after a few writes it has three partitions:

ls -1 /tmp/hudi_mor/.hoodie/metadata

column_stats
files
partition_stats

Each answers a different question, and only the first is about listing:

This is why the metadata table matters to an indexing decision rather than being a separate topic. column_stats is what lets a read skip files by predicate, and it is also the substrate the record index builds on. A table with the metadata table disabled falls back to listing storage, and every index type gets slower at exactly the scale where you needed the index.

It is itself a Hudi table, which is the elegant part and the operational catch: it is a Merge-on-Read table with its own timeline and its own compaction, so it needs the same care as any other. If it falls behind, reads that depend on it fall behind too.

Which one should I pick?

A decision order that holds for most tables:

That last row is worth saying out loud, because part of choosing well is recognising when you need less machinery. An append-only pipeline can set hoodie.datasource.write.operation to insert or bulk_insert, skip tagging entirely, and avoid maintaining a second table to answer a question whose answer is always “not present”.

On Flink, INMEMORY and FLINK_STATE are the engine defaults because the Flink writer already holds the index in its state backend, so you get fast tagging without configuring anything.

How do I confirm it is working?

A well-matched index is easy to check, and each signal points at a specific adjustment if you want one.

Two checks worth building into a review. Read the table’s hoodie.properties alongside the writer configs and confirm hoodie.index.type is a value somebody chose. Then list <base_path>/.hoodie/metadata/record_index/ and count file groups: a handful for a partitioned index, and tens to hundreds for a global one on a large table, is the shape you want.

Frequently asked questions

Can I change the index type on an existing table? Not casually. The index is how Hudi locates existing records, so switching types means the new index has to be built over the data already there. Plan it as a migration with a bootstrap step, not as a config edit between two runs.

Does a record index speed up my queries? No. Tagging is a write-path concern. Query-side skipping comes from column_stats and partition_stats, and from secondary indexes for non-key columns. They are separate partitions of the metadata table with separate configs.

My keys are UUIDs. Is BLOOM a bad idea? It works, it just has less to prune. Bloom pruning leans on key ranges being narrow enough to skip files, and random keys spread across every range. That is the case a record index was built for.

Do I need to turn the metadata table on separately? hoodie.metadata.enable has defaulted to true since 0.7.0, so usually not. You do need to enable the specific index you want, since both record-index enable flags default to false.

What happens if I set RECORD_INDEX in 1.2.0? It still works. It is deprecated, not removed, and it means the global index. GLOBAL_RECORD_LEVEL_INDEX is the same thing under the name you should be writing now.

Conclusion

Back to the job that got slower as the table grew. The reframe that makes that tractable is to stop thinking about index types and ask one question instead: does this write’s cost track my batch, or my table? If write time stays flat while the table grows, the index is doing its job and you can spend your tuning attention somewhere else. If it climbs with the table, tagging is scanning, and the table above tells you what to reach for.

The 1.2.0 naming is a real improvement worth adopting. RECORD_INDEX and hoodie.metadata.record.index.enable keep working, so the upgrade is uneventful, and the new pair makes the choice explicit: GLOBAL_RECORD_LEVEL_INDEX when a key identifies a row across the whole table, RECORD_LEVEL_INDEX when it identifies a row within a partition. Partitioned tables get the cheaper index and a much smaller metadata footprint for two config lines.

Treat the decision order here as a starting point and then measure on your own data. Both inputs, your batch size relative to your table and how your keys are distributed, are things you can observe directly rather than guess at, which is what makes this one of the friendlier tuning decisions Hudi puts in front of you.

References

• Hudi indexing documentation for the conceptual overview and engine support
• HoodieIndex.java, the authoritative IndexType list and the deprecation note
• HoodieMetadataConfig.java for the record-index keys, aliases and file-group defaults
• HoodieIndexConfig.java for hoodie.index.type and the per-engine default
• Hudi metadata table documentation for the partitions under .hoodie/metadata and their compaction
