Apache XTable cheat sheet: one table, every format

• What does XTable actually do?
• Which formats convert to which?
• Where does the converted metadata land?
• Architecture: three pieces and an internal model
• What ships in 0.4.0?
• How do I build it?
• Quick start: a Hudi table read as Iceberg and Delta
• Every RunSync flag
• How do I register the result in a catalog?
  • Doing it for many tables with RunCatalogSync
• Is there an API instead of a CLI?
• What does the sync not cover?
• Which engines can read the result?
• Trying it without installing anything
• Production tips
• Frequently asked questions
• Conclusion
• References
• Trademarks

TL;DR

• XTable writes metadata, never data. One directory of Parquet files ends up carrying .hoodie/, metadata/ and _delta_log/ side by side, and no record is copied.
• The authoritative format list is one file, xtable-conversion-defaults.yaml. Hudi, Iceberg and Delta convert in both directions; Paimon is source only; Parquet has a source provider but is not in the defaults, so it needs an explicit converters config.
• 0.4.0 makes the bundled jar runnable again, so java -jar works and the old jol-core classpath workaround is gone.
• xtable-utilities is not published to Maven Central. You build it. xtable-core, xtable-api, xtable-service and the new xtable-spark-runtime are published.
• Only Copy-on-Write or read-optimized views convert. Hudi log files and Delta or Iceberg deletion vectors are not captured, so on a Merge-on-Read source the converted formats are as fresh as the last compaction.

There is a particular kind of meeting where someone says the data is in Hudi and someone else says their warehouse only reads Iceberg, and the next forty minutes go on who is going to maintain the copy. XTable removes the meeting. The Parquet files stay exactly where they are, and a second set of metadata appears beside the first describing the same files in another format.

This is the reference page for doing that: what converts to what, where the output lands, how to build the tool, every flag it takes, and how to register the result so an engine can find it by name. It is written to be kept open in a tab rather than read once.

Written against the latest XTable release, 0.4.0-incubating as of now, published in August 2026. Every class, config key and bundled version below was read from the 0.4.0-incubating tag rather than recalled. Assumed knowledge: you have at least one lakehouse table already. For how XTable decides between a full and an incremental pass, see Apache XTable incremental sync.

What does XTable actually do?

It reads the metadata of a table you already have, builds a format-neutral description of it in memory, and writes that description out in the metadata language of another format. The Parquet files are never opened for their contents and never rewritten.

flowchart LR
  P[("Parquet data files<br/>written once")] --- H["<b>.hoodie/</b><br/>Hudi timeline"]
  P --- I["<b>metadata/</b><br/>Iceberg snapshots"]
  P --- D["<b>_delta_log/</b><br/>Delta log"]
  H --> E1["Spark, Flink, Trino"]
  I --> E2["Snowflake, BigQuery, Athena"]
  D --> E3["Databricks, Fabric"]

Three consequences follow, and they are the whole value proposition:

• A conversion costs metadata time, not data time. The work scales with how many commits and files the table has, not with how many rows.
• There is one copy of the truth. Nothing can drift, because there is nothing to drift from. The formats disagree only about how they describe the same files.
• It is not a runtime. XTable is a tool you invoke, on a schedule or after an ingest job. It does not sit in the query path, and it is not a new storage format to adopt.

Which formats convert to which?

The honest answer is one file in the repository, xtable-conversion-defaults.yaml, which maps each format name to the provider classes that can read and write it. Read it as the matrix rather than trusting a diagram:

Two entries need a note, because both are new and neither behaves like the first three.

Paimon is a source only. A Paimon table can be exposed as Hudi, Iceberg or Delta. Nothing converts back into Paimon, because no Paimon target is registered.

Parquet is a source that the defaults do not list. The provider class exists and the release notes describe partition extraction and incremental sync for it, but xtable-conversion-defaults.yaml has no PARQUET entry, so RunSync will reject it with “Source format PARQUET is not supported” unless you pass your own converters config with --convertersConfig. The constant class tells the same story from the other side: TableFormat declares five names, and its values() helper returns four, leaving PARQUET out.

There is also a second implementation of the Delta target. DeltaKernelConversionTarget is registered alongside the original and its getTableFormat() returns TableFormat.DELTA, so it is not a new format but an alternative writer built on Delta Kernel 4.0.0. You select it by overriding conversionTargetProviderClass for DELTA in a converters config.

Where does the converted metadata land?

In the place each format expects, inside the table directory. Nothing moves.

s3a://lakehouse-prod/warehouse/trips/
├── city_id=sf/
│   └── 8f3a1c92-...-0_0-24-1893_20260916090000123.parquet
├── city_id=nyc/
│   └── b2e7d410-...-0_0-25-1894_20260916090000123.parquet
├── .hoodie/          <- the source, written by your Hudi pipeline
├── metadata/         <- written by XTable, Iceberg reads this
└── _delta_log/       <- written by XTable, Delta reads this

The practical consequence is that a table which has been converted looks, to any engine you point at it, like a native table of that format. There is no shim to install on the read side and no XTable process running when the query runs.

Architecture: three pieces and an internal model

XTable’s design is a hub and spoke, and the hub is what makes it N formats rather than N times N converters.

flowchart TB
  SRC["<b>ConversionSource</b><br/>org.apache.xtable.spi.extractor<br/>one reader per source format"]
  MODEL["<b>InternalTable, InternalSchema</b><br/>format-neutral description:<br/>schema, partitioning, data files, commits"]
  CTRL["<b>ConversionController</b><br/>org.apache.xtable.conversion<br/>picks FULL or INCREMENTAL, commits each target"]
  TGT["<b>ConversionTarget</b><br/>org.apache.xtable.spi.sync<br/>one writer per target format"]
  SRC --> MODEL --> CTRL --> TGT

Adding a format means writing one source or one target against the model, not a converter for every other format. That is why Paimon arriving in 0.4.0 made it readable as three formats at once rather than as one.

What ships in 0.4.0?

XTable does the conversion using its own bundled copies of the format libraries, so these versions are not trivia. They are the compatibility contract for your source table.

Check your source table against the matching row before assuming a conversion will work, particularly for Hudi, where table versions move between releases.

What is new in this release, in the order it will matter to you:

• The bundled jar is runnable again. The shade plugin sets org.apache.xtable.utilities.RunSync as the main class, so java -jar works without naming the class.
• jol-core is now inside the jar. Hudi’s ObjectSizeCalculator loads it at runtime, and its absence used to surface as NoClassDefFoundError: org/openjdk/jol/info/GraphLayout. The pom now pulls it into the shaded artifact deliberately, with a comment saying why.
• xtable-spark-runtime is a new module, published as xtable-spark-runtime_2.12, described in the release notes as a thin drop-in Spark bundle for Spark 3.4 and 3.5.
• Paimon and Parquet sources, as covered above.
• A Maven wrapper. Build with ./mvnw and you get the version the project expects.

How do I build it?

There is no published xtable-utilities artifact on Maven Central, so the CLI is something you build. Java 11 is what the project asks for.

git clone https://github.com/apache/incubator-xtable.git
cd incubator-xtable
./mvnw clean package -DskipTests

The shaded artifact carries the bundled classifier, so glob for it rather than typing a version that will be stale next release:

export XTABLE_JAR=$(ls xtable-utilities/target/xtable-utilities_*-bundled.jar)
java -jar "$XTABLE_JAR" --help

If you are embedding XTable in your own job instead of shelling out to the CLI, these are on Maven Central at 0.4.0-incubating:

<dependency>
  <groupId>org.apache.xtable</groupId>
  <artifactId>xtable-core_2.12</artifactId>
  <version>0.4.0-incubating</version>
</dependency>

xtable-api, xtable-service and xtable-spark-runtime_2.12 are published at the same version. Only the Scala 2.12 build is published, so there is no 2.13 artifact to pick.

Quick start: a Hudi table read as Iceberg and Delta

Versions below match what XTable 0.4.0 bundles, which is the combination least likely to surprise you.

1. Write a Hudi table.

pyspark \
  --packages org.apache.hudi:hudi-spark3.4-bundle_2.12:0.14.0 \
  --conf "spark.serializer=org.apache.spark.serializer.KryoSerializer" \
  --conf "spark.sql.extensions=org.apache.spark.sql.hudi.HoodieSparkSessionExtension" \
  --conf "spark.sql.catalog.spark_catalog=org.apache.spark.sql.hudi.catalog.HoodieCatalog"

table_path = "file:///tmp/lakehouse/trips"

trips = spark.createDataFrame(
    [("trip-1001", "rider-88", 24.50, 1758000000, "sf"),
     ("trip-1002", "rider-12", 61.75, 1758000060, "nyc"),
     ("trip-1003", "rider-88", 18.20, 1758000120, "sf")],
    ["trip_id", "rider_id", "fare_amount", "updated_at", "city_id"])

(trips.write.format("hudi")
    .option("hoodie.table.name", "trips")
    .option("hoodie.datasource.write.recordkey.field", "trip_id")
    .option("hoodie.datasource.write.precombine.field", "updated_at")
    .option("hoodie.datasource.write.partitionpath.field", "city_id")
    .option("hoodie.datasource.write.hive_style_partitioning", "true")
    .mode("overwrite")
    .save(table_path))

spark.read.format("hudi").load(table_path).show()

Leave this shell with exit() before the next step. Each format wants its own runtime on the classpath.

2. Describe the conversion. Save as trips_sync.yaml:

sourceFormat: HUDI
targetFormats:
  - ICEBERG
  - DELTA
datasets:
  - tableBasePath: file:///tmp/lakehouse/trips
    tableName: trips
    partitionSpec: city_id:VALUE

sourceFormat can be auto-detected, but the javadoc recommends setting it explicitly, because a directory that has already been converted contains metadata for several formats and the guess becomes ambiguous. partitionSpec is only needed when the source table is partitioned.

3. Run it.

export XTABLE_JAR=$(ls xtable-utilities/target/xtable-utilities_*-bundled.jar)
java -jar "$XTABLE_JAR" --datasetConfig trips_sync.yaml

The line to grep for comes from ConversionController:

INFO org.apache.xtable.conversion.ConversionController - Sync is successful for the following formats [ICEBERG, DELTA]

There is a matching failure line, Sync failed for the following formats, and a run can produce both when one target succeeds and another does not. Check for the failure line rather than only for the success one.

4. Read the same directory as Iceberg.

pyspark \
  --packages org.apache.iceberg:iceberg-spark-runtime-3.4_2.12:1.9.2 \
  --conf "spark.sql.extensions=org.apache.iceberg.spark.extensions.IcebergSparkSessionExtensions" \
  --conf "spark.sql.catalog.spark_catalog=org.apache.iceberg.spark.SparkSessionCatalog"

spark.read.format("iceberg").load("file:///tmp/lakehouse/trips").show()

5. Read the same directory as Delta.

pyspark \
  --packages io.delta:delta-core_2.12:2.4.0 \
  --conf "spark.sql.extensions=io.delta.sql.DeltaSparkSessionExtension" \
  --conf "spark.sql.catalog.spark_catalog=org.apache.spark.sql.delta.catalog.DeltaCatalog"

spark.read.format("delta").load("file:///tmp/lakehouse/trips").show()

Same three rows, same Parquet files, three formats.

Every RunSync flag

java -jar "$XTABLE_JAR" \
  --datasetConfig trips_sync.yaml \
  --hadoopConfig core-site.xml \
  --convertersConfig my_converters.yaml \
  --icebergCatalogConfig iceberg_catalog.yaml \
  --continuousMode \
  --continuousModeInterval 60

--continuousMode is the one worth a second look. Because it re-reads the dataset config on every pass, you add or remove tables by editing a file rather than by restarting the job, which makes it a small service instead of a cron entry.

And the dataset config has more fields than most examples show:

How do I register the result in a catalog?

Conversion makes the metadata. Registration makes an engine able to find it by name. They are separate steps, and you need both.

For Iceberg, XTable writes through Iceberg’s HadoopTables API, so version-hint.text holds the current metadata version and the file to register is the matching v<N>.metadata.json:

cat /tmp/lakehouse/trips/metadata/version-hint.text

Then register it from a session that defines the catalog you are registering into:

spark-sql \
  --packages org.apache.iceberg:iceberg-spark-runtime-3.4_2.12:1.9.2 \
  --conf "spark.sql.extensions=org.apache.iceberg.spark.extensions.IcebergSparkSessionExtensions" \
  --conf "spark.sql.catalog.hive_prod=org.apache.iceberg.spark.SparkCatalog" \
  --conf "spark.sql.catalog.hive_prod.type=hive" \
  --conf "spark.sql.catalog.hive_prod.uri=thrift://metastore.internal:9083"

CREATE SCHEMA IF NOT EXISTS hive_prod.iceberg_db;

-- version-hint.text printed the N to use here
CALL hive_prod.system.register_table(
  table         => 'hive_prod.iceberg_db.trips',
  metadata_file => 'file:///tmp/lakehouse/trips/metadata/v3.metadata.json'
);

SELECT city_id, count(*) FROM hive_prod.iceberg_db.trips GROUP BY city_id;

Delta is simpler, because a location is enough:

CREATE SCHEMA IF NOT EXISTS delta_db;

CREATE TABLE IF NOT EXISTS delta_db.trips
USING DELTA LOCATION 'file:///tmp/lakehouse/trips';

SELECT city_id, count(*) FROM delta_db.trips GROUP BY city_id;

Doing it for many tables with RunCatalogSync

RunCatalogSync registers converted tables into external catalogs in one run, so nobody runs DDL by hand. Two catalog clients are registered through the service loader in 0.4.0: HMSCatalogSyncClient for Hive Metastore and GlueCatalogSyncClient for AWS Glue. The docs describe those two as the current support, with Unity Catalog, Apache Polaris, Apache Gravitino and DataHub listed as coming.

sourceCatalog:
  catalogId: "hms-source"
  catalogType: "HMS"
  catalogProperties:
    externalCatalog.hms.serverUrl: "thrift://metastore.internal:9083"
targetCatalogs:
  - catalogId: "glue-target"
    catalogSyncClientImpl: "org.apache.xtable.glue.GlueCatalogSyncClient"
    catalogProperties:
      externalCatalog.glue.region: "us-west-2"
datasets:
  - sourceCatalogTableIdentifier:
      tableIdentifier:
        hierarchicalId: "hudi_db.trips"
        partitionSpec: "city_id:VALUE"
    targetCatalogTableIdentifiers:
      - catalogId: "glue-target"
        tableFormat: "ICEBERG"
        tableIdentifier:
          hierarchicalId: "iceberg_db.trips"

java -cp "$XTABLE_JAR" \
  org.apache.xtable.utilities.RunCatalogSync \
  --catalogSyncConfig trips_catalog.yaml

Note the -cp and explicit class: only RunSync is the jar’s main class, so RunCatalogSync is named. Its flags are --catalogSyncConfig (required), --hadoopConfig and --convertersConfig. Every catalogId under datasets must match one declared in sourceCatalog or targetCatalogs, or the config is rejected.

Is there an API instead of a CLI?

Yes, and it is the part of the project moving fastest. xtable-service is published on Maven Central at 0.4.0-incubating, and the repository carries an OpenAPI description at spec/rest-service-open-api.yaml defining two operations:

The shape tells you it is asynchronous: you submit and then poll, rather than holding a connection open for the length of a sync. The spec is versioned 0.0.1, so treat it as early and pin what you build against it.

What does the sync not cover?

This is the section to read before anything else, because one line in the project’s own limitations page decides whether XTable fits your table at all:

Only Copy-on-Write or Read-Optimized views of tables are currently supported. This means that only the underlying parquet files are synced but log files from Hudi and delete vectors from Delta and Iceberg are not captured by the sync.

A Merge-on-Read Hudi table converts as its read-optimized view. Everything sitting in log files since the last compaction is not in the Iceberg or Delta metadata XTable writes. The conversion is not wrong, it is as of the last compaction, and a reader on the converted side sees exactly what a read_optimized query would see. The same applies to Delta and Iceberg deletion vectors on the source side.

If your Hudi table is Copy-on-Write, this costs you nothing. If it is Merge-on-Read, compaction frequency becomes the freshness bound on every converted format, which is a scheduling decision rather than a configuration one.

The other documented caveats, all of which are cheap to satisfy once you know:

XTable also does target-side housekeeping rather than leaving it to you: Hudi targets get unreferenced files marked for cleaning, Iceberg targets get snapshots expired after a configured age, and Delta targets get log retention.

Which engines can read the result?

Once the metadata is written, this stops being an XTable question. A converted table is an ordinary table of that format, and the project says so plainly: synced tables “behave the similarly to native tables which means you do not need any additional configurations on query engines’ side”.

So the useful list is not a support matrix but the set of engines the project documents, and which formats each page actually covers:

Snowflake being the one Iceberg-only page is the shape of the whole argument for this tool: the warehouse dictates the format, your ingestion pipeline does not have to change to satisfy it, and the gap between the two is metadata XTable can write. Check the engine docs for current, engine-specific instructions before you commit to one.

Trying it without installing anything

The repository ships a Docker demo with Spark on Jupyter, a Hive Metastore, Trino and Presto already wired together:

git clone https://github.com/apache/incubator-xtable.git
cd incubator-xtable/demo
./start_demo.sh

Querying the same table from Trino as Iceberg and from Presto as Delta, in two terminals, makes the point faster than any diagram.

Production tips

• Check your source table type first. A Merge-on-Read Hudi source converts as its read-optimized view, so compaction frequency, not sync frequency, bounds freshness on every target format.
• Pin the XTable version and the format libraries together. The conversion uses XTable’s bundled Hudi, Iceberg and Delta, not yours.
• Run the sync as the last step of ingestion, not on an independent timer, so a converted table is never newer or older than the commit it claims to describe.
• Grep for the failure line, not just the success line. A partially successful run logs both.
• Prefer --continuousMode over cron when you have more than a handful of tables, since it reloads its config without a restart.
• Set sourceFormat explicitly. After the first conversion the directory holds several formats and auto-detection has more than one right answer.
• Treat catalog registration as a separate job with its own alerting. A converted table nobody registered is invisible, and it fails silently.
• Remember XTable is incubating. The disclaimer in the repository is not a formality: config shapes and module names have moved between releases, and the REST spec is at 0.0.1.

Frequently asked questions

Does converting cost me a rewrite of the data? No. Only metadata is written. The cost scales with commits and file counts, not with rows, so a large table costs about what a small one does.

Can I write through both formats at once? Treat one format as the writer and the others as read-only projections of it. Two writers committing to the same files through different metadata trees have no shared concurrency control, and nothing coordinates them.

Why does my Parquet source fail with “not supported”? xtable-conversion-defaults.yaml has no PARQUET entry even though ParquetConversionSourceProvider exists. Supply a converters config with --convertersConfig naming that provider class.

Can I convert to Paimon? Not in 0.4.0. Paimon is a source only, since no Paimon target is registered.

What happened to OneTable? Same project, renamed on entering the Apache Incubator. Artifacts and packages are org.apache.xtable; anything naming OneTable predates the donation.

How do I know a run was incremental rather than full? The controller logs its fallback, including “No previous InternalTable sync for target. Falling back to snapshot sync.” The incremental sync post goes through the decision in detail.

Conclusion

The idea underneath all of this is smaller than the tooling around it. A table format is a description of a set of files, the files are ordinary Parquet, and nothing stops one set of files from carrying several descriptions at once. Once you accept that, the copy everyone was arguing about in the meeting turns out to be metadata, and metadata is cheap to produce twice.

What 0.4.0 adds is mostly the unglamorous kind of progress that makes a tool usable: a jar that runs with java -jar, a dependency that no longer has to be bolted onto the classpath by hand, a Maven wrapper, a Spark runtime bundle. The new sources matter too, because a Paimon or Parquet table becoming readable as three formats is the clearest demonstration that the hub-and-spoke model was worth building.

Where it does not fit: if you only ever use one engine, you are adding a moving part for a problem you do not have. XTable earns its keep when the write side and the read side want different formats and neither is willing to move. That is a common situation, and paying for it in metadata rather than in storage and a sync pipeline is a good trade.

References

• Apache XTable documentation for the quickstart and catalog guides
• 0.4.0-incubating release notes for the full change list behind this page
• xtable-conversion-defaults.yaml at 0.4.0-incubating, the authoritative source and target matrix
• RunSync.java at 0.4.0-incubating for every flag and config field
• Apache XTable incremental sync for how the sync mode is chosen

Trademarks

Apache XTable (incubating), Apache Hudi, Apache Iceberg, Apache Paimon, Apache Parquet, Apache Spark, Apache Flink, Apache Avro, Apache Hive and Apache are either registered trademarks or trademarks of The Apache Software Foundation in the United States and other countries. Delta Lake is a trademark of the Linux Foundation. All other marks are the property of their respective owners.
